Products Specifications:
Main Specification
| No. |
Specification |
Unit |
Machine Model |
||||||
|
VT-300/VT-300E |
|||||||||
|
1 |
Max. Punch Force |
kN |
300 |
||||||
|
2 |
Main Driving Type |
/ |
Hydraulic driving type |
||||||
|
3 |
CNC System |
/ |
FANUC |
||||||
|
4 |
Max. Sheet Processing Size (with one reposition) |
mm |
1250×2500 |
1250×4000 |
1250×5000 |
1500×4000 |
1500×5000 |
||
|
5 |
No. of Clamp |
no. |
2 |
3 |
|||||
|
6 |
Max. Processing Sheet Thickness |
mm |
6.35 |
||||||
|
7 |
Max. Punch Diameter per Time |
mm |
F88.9 |
||||||
|
8 |
Main Cylinder Stroke |
mm |
40 |
||||||
|
9 |
Max. Punch Hit at 1mm Pace |
hpm |
600 |
||||||
|
10 |
Max. Punch Hot at 25mm Pace |
hpm |
350 |
320 |
320 |
300 |
300 |
||
|
11 |
Max. Nibbling Speed |
hpm |
/ |
||||||
|
12 |
No. of Repositioning Cylinder |
set |
2 |
||||||
|
13 |
No. of Station |
no. |
32 |
||||||
|
14 |
No. of AI |
no. |
2 (can be expanded) |
||||||
|
15 |
No. of Controlling Axis |
no. |
4 |
||||||
|
16 |
Tooling Type |
/ |
Long type/Short type |
||||||
|
17 |
Machine Structure |
|
VT-300: Closed O type/VT-300E: Closed stream-line type |
||||||
|
18 |
Beam Structure |
|
Single guideway |
Double guideway |
|||||
|
19 |
Worktable Type |
/ |
Ball & brush mixed (full brush table is option) |
||||||
|
20 |
Max. Feeding Speed |
X Axis |
m/min |
60 |
|||||
|
Y Axis |
60 |
||||||||
|
XY Combined |
85 |
||||||||
|
21 |
Turret Speed |
rpm |
30 |
||||||
|
22 |
Tooling Rotation Speed |
rpm |
60 |
||||||
|
23 |
Accuracy |
mm |
±0.1 |
||||||
|
24 |
Max. Load Capacity |
Kg |
150 |
||||||
|
25 |
Main Motor Power |
kVA |
11 |
||||||
|
26 |
Air Pressure |
MPa |
0.55 |
||||||
|
27 |
Gas Consumption |
L/ min |
250 |
||||||
|
28 |
CNC Memory Capacity |
/ |
512KB |
||||||
|
29 |
Outline Dimension |
mm |
5020x2680 x2340.5 |
5520x4300 |
5020x5000 x2340.5 |
5520x4300 |
5520x5000 |
||
